This page gives a quick overview of all the important topics to get started with...
Before you start, you should be aware of some safety aspects. Although such lasers have...
Getting started Within this guide, I currently will not cover the unboxing and assembly of...
| Material Name | Thickness(mm) | Processing | Power(%) / Speed(mm/s) / Pass |
|---|---|---|---|
| Plywood | 3MM | Cutting | 300mm/min 2 passes power 100% |
| Plywood | 6MM | Cutting | 300mm/min 4 passes power 100% |
| Plywood | 10MM | Cutting | / |
| Plywood | / | Engravin | 3000mm/min power 43% |
| Basswood | 3MM | Cutting | 300mm/min 2 passes power 100% |
| Basswood | 6MM | Cutting | 180mm/min 3 passes power 100% |
| Tung board/cork | 10MM | Cutting | 360mm/min 5 passes power 100% |
| Tung board/cork | 15MM | Cutting | 180mm/min 8 passes power 100% |
| Tung board/cork | 20MM | Cutting | / |
| Black Acrylic | 6MM | Cutting | 180mm/min 6 passes power 100% |
| Black Acrylic | 11MM | Cutting | / |
| MDF | 3.6MM | Cutting | 180mm/min 4 passes power 100% |
| MDF | / | Engravin | 3000mm/min power 35% |
| Stainless steel | / | Engravin | 180mm/min power 100% |
| g Kraft paper | / | Engravin | 1800mm/min power 25% |
| Leatherwear | / | Engravin | 1800mm/min power 15% |
| The limit test parameters are for reference only, and the actual parameters need to be adjusted according to the actual material thickness | |||
| Material Name | Thickness(mm) | Processing | Power(%) / Speed(mm/s) / Pass |
|---|---|---|---|
| Plywood | 3MM | Cutting | 300mm/min 1 passes power 100% Air On |
| Plywood | 6MM | Cutting | 240mm/min 3 passes power 100% Air On |
| Plywood | 10MM | Cutting | 180mm/min 12 passes power 100% Air On |
| Plywood | / | Engravin | 3000mm/min power 43% |
| Basswood | 3MM | Cutting | 240mm/min 1 passes power 100% Air On |
| Basswood | 6MM | Cutting | 180mm/min 2 passes power 100% Air On |
| Tung board/cork | 10MM | Cutting | 300mm/min 4 passes power 100% Air On |
| Tung board/cork | 15MM | Cutting | 300mm/min 7 passes power 100% Air On |
| Tung board/cork | 20MM | Cutting | / |
| Black Acrylic | 6MM | Cutting | 180mm/min 5 passes power 100% Air On |
| Black Acrylic | 11MM | Cutting | / |
| MDF | 3.6MM | Cutting | 180mm/min 4 passes power 100% Air On |
| MDF | / | Engravin | 3000mm/min power 35% |
| Stainless steel | / | Engravin | 180mm/min power 100% |
| g Kraft paper | / | Engravin | 1800mm/min power 25% |
| Leatherwear | / | Engravin | 1800mm/min power 15% |
| The limit test parameters are for reference only, and the actual parameters need to be adjusted according to the actual material thickness | |||
| Material Name | Thickness(mm) | Processing | Power(%) / Speed(mm/s) / Pass |
|---|---|---|---|
| Plywood | 3MM | Cutting | 480mm/min 1 passes power 100% Air On |
| Plywood | 6MM | Cutting | 180mm/min 1 passes power 100% Air On |
| Plywood | 10MM | Cutting | 180mm/min 4 passes power 100% Air On |
| Plywood | / | Engravin | 3000mm/min power 30% |
| Basswood | 3MM | Cutting | 360mm/min 1 passes power 100% Air On |
| Basswood | 6MM | Cutting | 180mm/min 1 passes power 100% Air On |
| Tung board/cork | 10MM | Cutting | 300mm/min 2 passes power 100% Air On |
| Tung board/cork | 15MM | Cutting | 180mm/min 2 passes power 100% Air On |
| Tung board/cork | 20MM | Cutting | 300mm/min 10 passes power 100% Air On |
| Black Acrylic | 6MM | Cutting | 180mm/min 2 passes power 100% Air On |
| Black Acrylic | 11MM | Cutting | 180mm/min 11 passes power 100% Air On |
| MDF | 3.6MM | Cutting | 240mm/min 2 passes power 100% Air On |
| MDF | / | Engravin | 3000mm/min power 15% |
| Stainless steel | / | Engravin | 360mm/min power 100% |
| g Kraft paper | / | Engravin | 1800mm/min power 15% |
| Leatherwear | / | Engravin | 1800mm/min power 10% |
| The limit test parameters are for reference only, and the actual parameters need to be adjusted according to the actual material thickness | |||
| Material Name | Thickness(mm) | Processing | Power(%) / Speed(mm/s) / Pass |
|---|---|---|---|
| Plywood | 3MM | Cutting | 780mm/min 1 passes power 100% Air On |
| Plywood | 6MM | Cutting | 360mm/min 1 passes power 100% Air On |
| Plywood | 10MM | Cutting | 300mm/min 2 passes power 100% Air On |
| Plywood | / | Engravin | 3000mm/min power 20% |
| Basswood | 3MM | Cutting | 600mm/min 1 passes power 100% Air On |
| Basswood | 6MM | Cutting | 300mm/min 2 passes power 100% Air On |
| Tung board/cork | 10MM | Cutting | 300mm/min 2 passes power 100% Air On |
| Tung board/cork | 15MM | Cutting | 180mm/min 1 passes power 100% Air On |
| Tung board/cork | 20MM | Cutting | 180mm/min 3 passes power 100% Air On |
| Black Acrylic | 6MM | Cutting | 300mm/min 3 passes power 100% Air On |
| Black Acrylic | 11MM | Cutting | 180mm/min 6 passes power 100% Air On |
| MDF | 3.6MM | Cutting | 300mm/min 1 passes power 100% Air On |
| MDF | / | Engravin | 3000mm/min power 18% |
| Stainless steel | / | Engravin | 900mm/min power 100% |
| g Kraft paper | / | Engravin | 1800mm/min power 15% |
| Leatherwear | / | Engravin | 1800mm/min power 15% |
| The limit test parameters are for reference only, and the actual parameters need to be adjusted according to the actual material thickness | |||
